Grafton Dress, Top & Skirt Mix & Match Pack

from $25

Size Size guide

0-16 12-32

Pattern format

PDF Printed

Mix and match your way to a knit wardrobe that’s uniquely yours with the Grafton Dress, Top & Skirt Mix & Match Pack.

This curve-friendly sewing pattern comes with cup sizes C-H and multiple bodice, skirt, sleeve, and neckline options to make over 400 possible knit dresses, skirts, and tops. Sew a casual skater dress, a trendy asymmetrical skirt, a glamorous gown, an elevated tee, a retro frock, and so much more. You can craft a unique look every time you sew the Grafton!

This Cashmerette pattern includes:

Cup sizes from C to H
A sizing calculator which will tell you exactly which size to make
A beautifully illustrated and detailed instruction booklet, to guide you no matter your sewing level

Want to see how this pattern will look on you? Sketch your plans on a body outline croquis that's custom made to your measurements with MyBodyModel. Learn more »

Product information

SEWING LEVEL

Advanced beginner

SIZING

0 to 16, in three cup sizes (C/D, E/F, G/H); includes 33-46” bust and 35-46” hip. Find your size in seconds using our size calculator.

This pattern is also available in sizes 12-32 (sold separately).

RECOMMENDED FABRIC

Light- to mid-weight knit fabrics such as jersey, ITY, Liverpool knit, double knit, or ponte with at least 25% stretch both horizontally and vertically. There are two exceptions:

Relaxed bodice: at least 25% stretch horizontally, and at least 10% vertically.
A-line maxi skirt: due to the weight of the piece, 0-10% lengthwise stretch is ideal. You can use 25%+, but may need to adjust the length to account for the skirt stretching vertically.

If you are lining your bodice (for the square neckline, optional for all others), you can use the same fabric for the lining, or a lighter weight knit with the same amount of stretch.

Interfacing (turtle neckband only): lightweight stretch interfacing (optional)

NOTIONS

Ballpoint or stretch needle, thread, twin needle (optional for hem).

For elasticated waistband: 1 yd (1 m) of 1” (2.5 cm) wide elastic.

Optional: Clear elastic for shoulder seams (¾ yds/0.7 m), slash pocket openings (3/8 yd/0.3 m), and/or waist seam (1 yd/1 m).

Optional: Fusible hem tape (maximum of 6 yds /5.5 m).

Pattern features

Choose from numerous features that can be mixed and matched in over 400 combinations! Pattern features include:

BODICE

Relaxed bodice with dropped shoulders
Fitted bodice with waist darts
Each bodice can be made as a dress or top
Each bodice can be lined or unlined

NECKLINE

V neck with neckband or lining
Crew neck with neckband or lining
Scoop neck with neckband or lining
Turtleneck with neckband
Square neck with lining

SLEEVE

Relaxed bodice: grown-on drop sleeves or long sleeves
Fitted bodice: straight sleeves in short, mid, and long lengths; bishop sleeves; sleeveless with armhole facing or lining

SKIRT

A-line skirt in knee or maxi length with optional inseam pockets
Straight skirt in short, knee, or midi length with optional slash pockets and side slits
Asymmetrical draped skirt with optional slash pockets
3-panel circle skirt
Each skirt can be combined with any bodice option to make a dress or sewn on its own as a standalone skirt.

PDF pattern information

New to PDF sewing patterns? See our complete guide here.

The PDF comes in separate files so you only need to print the features you desire. You'll receive files to print at home or at a copy shop. Files are delivered as a .zip file which can be downloaded on a computer, but not on a mobile device. For more on PDFs, see the FAQs.

Total ZIP file size: 6.5 MB

Instructions: 49 pages

Print-at-home files:

Relaxed bodice: 33 pages
Fitted bodice, sleeved: 41 pages
Fitted bodice, sleeveless: 27 pages
Straight skirt: 10 pages
A-Line skirt: 16 pages
Asymmetric skirt: 18 pages
Circle skirt: 12 pages

Copy shop (A0 size) files:

Relaxed bodice pieces: 2 pages
Fitted bodice, sleeved: 2 pages
Fitted bodice, sleeveless: 2 pages
Straight skirt: 1 page
A-Line skirt: 1 page
Asymmetric skirt: 1 page
Circle skirt: 1 page

Model Details

Megha (floral dress, fuchsia top) is wearing a size 4 C/D graded to a 6 waist and 12 hip. Her measurements are high bust 32", full bust 34.5", waist 28", and hip 42", and she is 5' 2”.

Jan Marie (olive skirt, purple dress) is wearing a size 6 E/F. Her measurements are high bust 33.5", full bust 37", waist 28", and hip 38", and she is 5' 4”.

Ana (black and white dress, red & floral tops) is wearing a size 14 C/D. Her measurements are high bust 38", full bust 41", waist 34", and hip 44.5", and she is 5' 4”.

Learn More

Fabric Requirements & Measurements

Body Measurements (in), sizes 0-16

	0	2	4	6	8	10	12	14	16
High Bust	30	31	32	33	34	35 ½	37	39	41
Full Bust, C/D Cup	33	34	35	36	37	38 ½	40	42	44
Full Bust, E/F Cup	34	35	36	37	38	39 ½	41	43	45
Full Bust, G/H Cup	35	36	37	38	39	40.5	42	44	46
Waist	25	26	27	28	29	30.5	32	34	36
Hip	35	36	37	38	39	40.5	42	44	46
Bicep	9 ⅞	10 ¼	10 ⅝	11	11 ⅜	11 ⅞	12 ⅜	13 ¼	14 ⅛

Finished Garment Measurements (in), sizes 0-16

		0	2	4	6	8	10	12	14	16
Full Bust, Relaxed bodice	C/D	34 ⅛	35 ⅛	36 ⅛	37 ⅛	38 ⅛	39 ⅝	41 ⅛	43 ⅛	45 ⅛
	E/F	35 ⅛	36 ⅛	37 ⅛	38 ⅛	39 ⅛	40 ⅝	42 ⅛	44 ⅛	46 ⅛
	G/H	36 ⅛	37 ⅛	38 ⅛	39 ⅛	40 ⅛	41 ⅝	43 ⅛	45 ⅛	47 ⅛
Full Bust, Fitted Bodice	C/D	29 ¾	30 ¾	31 ¾	32 ¾	33 ¾	35 ¼	36 ¾	38 ¾	40 ¾
	E/F	30 ¾	31 ¾	32 ¾	33 ¾	34 ¾	36 ¼	37 ¾	39 ¾	41 ¾
	G/H	31 ¾	32 ¾	33 ¾	34 ¾	35 ¾	37 ¼	38 ¾	40 ¾	42 ¾
Waist (no elastic)	Skirt/Dress, all views	25	26	27	28	29	30 ½	32	34	36
	Top, Relaxed	31 ¼	32 ¼	33 ¼	34 ¼	35 ¼	36 ¾	38 ¼	40 ¼	42 ¼
	Top, Fitted	29	30	31	32	33	34 ½	36	38	40
Hip	A-Line Skirt	37 ⅛	38 ⅛	39 ⅛	40 ⅛	41 ⅛	42 ⅝	44 ⅛	46 ⅛	48 ⅛
	Straight Skirt	35 ⅛	36 ⅛	37 ⅛	38 ⅛	39 ⅛	40 ⅝	42 ⅛	44 ⅛	46 ⅛
	Asymmetrical Skirt	35	36	37	38	39	40 ½	42	44	46
	Circle Skirt	75 ⅜	76 ⅜	77 ⅜	78 ⅜	79 ⅜	80 ⅞	82 ⅜	84 ⅜	86 ⅜
	Top, relaxed & fitted	36 ⅝	37 ⅝	38 ⅝	39 ⅝	40 ⅝	42 ⅛	43 ⅝	45 ⅝	47 ⅝
Bicep	Long Sleeve	10 ½	11	11 ½	12	12 ½	13	13 ½	14	14 ½
	Straight Sleeve	10 ⅝	11 ¼	11 ⅞	12 ½	13 ⅛	13 ¾	14 ½	15 ¼	16 ⅛
	Bishop Sleeve	10 ½	11 ⅛	11 ¾	12 ⅜	12 ¾	13 ½	14 ⅜	15 ⅛	16
Back Length*	Relaxed Bodice	14 ⅛	14 ⅜	14 ⅝	14 ⅞	15 ⅛	15 ⅜	15 ⅝	15 ⅞	16 ⅛
	Fitted Bodice	13 ⅞	14 ⅛	14 ⅜	14 ⅝	14 ⅞	15 ⅛	15 ⅜	15 ⅝	15 ⅞
	A-Line Skirt, knee	22 ½	22 ½	22 ½	22 ½	22 ½	22 ½	22 ½	22 ½	22 ½
	A-Line Skirt, maxi	39	39	39	39	39	39	39	39	39
	Straight skirt, short	17 ¾	17 ¾	17 ¾	17 ¾	17 ¾	17 ¾	17 ¾	17 ¾	17 ¾
	Straight skirt, knee	22 ⅜	22 ⅜	22 ⅜	22 ⅜	22 ⅜	22 ⅜	22 ⅜	22 ⅜	22 ⅜
	Straight skirt, midi	27 ⅜	27 ⅜	27 ⅜	27 ⅜	27 ⅜	27 ⅜	27 ⅜	27 ⅜	27 ⅜
	Asymmetrical Skirt**	17 ⅜	17 ⅜	17 ⅜	17 ⅜	17 ⅜	17 ⅜	17 ⅜	17 ⅜	17 ⅜
	Circle Skirt	25	25	25	25	25	25	25	25	25
	Top, relaxed & fitted	21	21 ¼	21 ½	21 ¾	22	22 ¼	22 ½	22 ¾	23

*For dress length, add selected bodice length to selected skirt length

**Measured along short side seam to top of slit

Body Measurements (cm), sizes 0-16

	0	2	4	6	8	10	12	14	16
High Bust	76	79	81	84	86	90	94	99	104
Full Bust, C/D Cup	84	86	89	91	94	98	102	107	112
Full Bust, E/F Cup	86	89	91	94	97	100	104	109	114
Full Bust, G/H Cup	89	91	94	97	99	103	107	112	117
Waist	64	66	69	71	74	77	81	86	91
Hip	89	91	94	97	99	103	107	112	117
Bicep	25	26	27	28	29	30	31	34	36

Finished Garment Measurements (cm), sizes 0-16

		0	2	4	6	8	10	12	14	16
Full Bust, Relaxed bodice	C/D	87	89	92	94	97	101	104	110	115
	E/F	89	92	94	97	99	103	107	112	117
	G/H	92	94	97	99	102	106	110	115	120
Full Bust, Fitted Bodice	C/D	76	78	81	83	86	90	93	98	104
	E/F	78	81	83	86	88	92	96	101	106
	G/H	81	83	86	88	91	95	98	104	109
Waist (no elastic)	Skirt/Dress, all views	64	66	69	71	74	77	81	86	91
	Top, Relaxed	79	82	84	87	90	93	97	102	107
	Top, Fitted	74	76	79	81	84	88	91	97	102
Hip	A-Line Skirt	94	97	99	102	104	108	112	117	122
	Straight Skirt	89	92	94	97	99	103	107	112	117
	Asymmetrical Skirt	89	91	94	97	99	103	107	112	117
	Circle Skirt	191	194	197	199	202	205	209	214	219
	Top, relaxed & fitted	93	96	98	101	103	107	111	116	121
Bicep	Long Sleeve	27	28	29	30	32	33	34	36	37
	Straight Sleeve	27	29	30	32	33	35	37	39	41
	Bishop Sleeve	27	28	30	31	33	34	36	38	41
Back Length*	Relaxed Bodice	36	37	37	38	38	39	40	40	41
	Fitted Bodice	35	36	37	37	38	38	39	40	40
	A-Line Skirt, knee	57	57	57	57	57	57	57	57	57
	A-Line Skirt, maxi	99	99	99	99	99	99	99	99	99
	Straight skirt, short	45	45	45	45	45	45	45	45	45
	Straight skirt, knee	57	57	57	57	57	57	57	57	57
	Straight skirt, midi	70	70	70	70	70	70	70	70	70
	Asymmetrical Skirt**	44	44	44	44	44	44	44	44	44
	Circle Skirt	64	64	64	64	64	64	64	64	64
	Top, relaxed & fitted	53	54	55	55	56	57	57	58	58

*For dress length, add selected bodice length to selected skirt length

**Measured along short side seam to top of slit

Fabric Requirements, sizes 0-16

To find the total yardage required for the style of Grafton you are making, add up the applicable bodice, sleeve, and skirt yardages noted below.

45" and 55" wide fabric is listed in yards; 115 cm and 140 cm wide fabric is listed in meters.

Bodices

RELAXED BODICE, Sleeved or Sleeveless, All necklines - Main		0 - 4	6 - 10	12 - 16
45" wide	Dress bodice (w/ or w/o waistband)	1 ¼	1 ⅜	1 ½
	Top	1 ⅝	1 ¾	2
55" wide	Dress bodice (w/ or w/o waistband)	⅞	1	1 ¼
	Top	1 ⅛	1 ⅛	1 ¾
115 cm wide	Dress bodice (w/ or w/o waistband)	1.2	1.2	1.4
	Top	1.5	1.6	1.8
140 cm wide	Dress bodice (w/ or w/o waistband)	0.8	0.9	1.2
	Top	1	1.1	1.5

RELAXED BODICE, Sleeved or Sleeveless, All necklines, W/ or w/o waistband - Lining		0 - 4	6 - 10	12 - 16
45" wide	Dress bodice (w/ or w/o waistband)	1 ¼	1 ¼	1 ¼
	Top	1 ½	1 ⅝	1 ⅝
55" wide	Dress bodice (w/ or w/o waistband)	¾	¾	1 ¼
	Top	⅞	⅞	1 ⅝
115 cm wide	Dress bodice (w/ or w/o waistband)	1.1	1.1	1.2
	Top	1.4	1.5	1.5
140 cm wide	Dress bodice (w/ or w/o waistband)	0.6	0.6	1.1
	Top	0.8	0.8	1.5

FITTED BODICE, Sleeved or Sleeveless, All necklines, W/ or w/o waistband - Main		0 - 4	6 - 10	12 - 16
45" wide	Dress bodice (w/ or w/o waistband)	⅞	⅞	1 ⅛
	Top	1 ¼	1 ⅜	1 ¾
55" wide	Dress bodice (w/ or w/o waistband)	¾	⅞	1
	Top	1 ⅛	1 ¼	1 ¼
115 cm wide	Dress bodice (w/ or w/o waistband)	0.8	0.8	1
	Top	1	1.2	1.6
140 cm wide	Dress bodice (w/ or w/o waistband)	0.7	0.8	0.9
	Top	1	1.1	1.1

FITTED BODICE, Sleeved or Sleeveless, All necklines, W/ or w/o waistband - Lining		0 - 4	6 - 10	12 - 16
45" wide	Dress bodice (w/ or w/o waistband)	⅝	⅝	1
	Top	⅞	1 ⅛	1 ⅝
55" wide	Dress bodice (w/ or w/o waistband)	⅝	⅝	¾
	Top	⅞	⅞	1
115 cm wide	Dress bodice (w/ or w/o waistband)	0.6	0.6	0.9
	Top	0.8	1.1	1.5
140 cm wide	Dress bodice (w/ or w/o waistband)	0.6	0.6	0.7
	Top	0.8	0.8	0.9

Sleeves

SLEEVES, relaxed bodice		0 - 4	6 - 10	12 - 16
45" wide	Long sleeve	⅝	⅝	⅝
55" wide	Long sleeve	⅝	⅝	⅝
115 cm wide	Long sleeve	0.6	0.6	0.6
140 cm wide	Long sleeve	0.6	0.6	0.6

SLEEVES, fitted bodice		0 - 4	6 - 10	12 - 16
45" wide	Straight sleeve - short	⅜	⅜	⅜
	Straight sleeve - mid	⅝	⅝	⅝
	Straight sleeve - long	⅞	⅞	⅞
	Bishop sleeve	1	1 ⅛	1 ⅛
55" wide	Straight sleeve - short	⅜	⅜	⅜
	Straight sleeve - mid	⅝	⅝	⅝
	Straight sleeve - long	⅞	⅞	⅞
	Bishop sleeve	⅞	⅞	⅞
115 cm wide	Straight sleeve - short	0.4	0.4	0.4
	Straight sleeve - mid	0.5	0.5	0.6
	Straight sleeve - long	0.8	0.8	0.8
	Bishop sleeve	0.9	1	1
140 cm wide	Straight sleeve - short	0.4	0.4	0.4
	Straight sleeve - mid	0.5	0.5	0.6
	Straight sleeve - long	0.8	0.8	0.8
	Bishop sleeve	0.7	0.7	0.8

Skirts

A-LINE SKIRT (w/ or w/o bodice & waistband; w/ or w/o pockets)		0 - 4	6 - 10	12 - 16
45" wide	Knee length	1 ¾	1 ¾	1 ⅞
	Maxi length	2 ¾	2 ¾	2 ¾
55" wide	Knee length	1 ½	1 ⅝	1 ¾
	Maxi length	2 ⅝	2 ⅝	2 ⅝
115 cm wide	Knee length	1.6	1.6	1.7
	Maxi length	2.5	2.5	2.5
140 cm wide	Knee length	1.4	1.5	1.5
	Maxi length	2.4	2.4	2.4

STRAIGHT SKIRT (w/ or w/o bodice & waistband; w/ or w/o pockets)		0 - 4	6 - 10	12 - 16
45" wide	Short length	1 ¼	1 ⅜	1 ⅜
	Knee length	1 ⅜	1 ½	1 ¾
	Midi length	1 ½	1 ⅝	2
55" wide	Short length	1 ⅛	1 ¼	1 ¼
	Knee length	1 ¼	1 ¼	1 ⅜
	Midi length	1 ⅜	1 ⅜	1 ½
115 cm wide	Short length	1.1	1.2	1.4
	Knee length	1.2	1.3	1.6
	Midi length	1.4	1.4	1.7
140 cm wide	Short length	1	1.1	1.1
	Knee length	1.1	1.1	1.3
	Midi length	1.2	1.2	1.4

ASYMMETRICAL SKIRT (w/ or w/o bodice & waistband; w/ or w/o pockets)	0 - 4	6 - 10	12 - 16
45" wide	1 ¾	2	2 ¼
55" wide	1 ½	1 ½	1 ¾
115 cm wide	1.6	1.8	2.1
140 cm wide	1.3	1.4	1.7

CIRCLE SKIRT (w/ or w/o bodice & waistband)	0 - 4	6 - 10	12 - 16
45" wide	3 ⅝	3 ⅞	4 ⅛
55" wide	3 ¼	3 ⅜	3 ½
115 cm wide	3.3	3.5	3.7
140 cm wide	2.9	3	3.1

See #graftondress on Instagram

See what our customers are making

Perfect bridesmaid dress

I made the square neckline, fitted bodice, and the A line skirt. I added flutter sleeves from a different pattern. Added a belt and boom! Bridesmaid ready! Loads of compliments. Instructions and drafting are wonderful. Can’t wait to try different variations!

Grafton Dress, Top & Skirt Mix & Match Pack 12-32 PDF pattern

good

made a dress with fitted top, turtle neck and a-line skirt and am quite pleased with the outcome. Its a bit more relaxed than my beloved Rivermont dress (made at least 7 of this pattern), but much faster to sew. Will try other variations soon

Such an adaptable and flexible pattern. I love it!

I haven’t yet made a full Grafton dress, but I’ve used the skirt and sleeves with the Dewey dress.
I had made the Dewey with the faux wrap skirt in a sequinned jersey, then wanted to wear the dress for a social ballroom and Latin dance. The original skirt was too narrow for ballroom dancing, so I took it off and managed to find enough of the remaining fabric to do the Grafton full circle skirt.
I received so many compliments on both versions of the dress. Looking forward to making a full Grafton soon.

Fantastic

I have been looking for a pattern like this for a long time. Fits fabulously, already made three garments.

Awesome pattern

I love this pattern so much! I have made a dress and a top. I love the square neckband and bishop sleeves but I also love how many mix and match variations there are. It's not a cheap pattern but totally worth it and great value. It's helped me fall in love with stretch sewing again. Oh and it's really quite an easy quick sew. Best pattern I've ever bought.

1 2

Grafton Dress, Top & Skirt Mix & Match Pack

Grafton Dress, Top & Skirt Mix & Match Pack

Size Size guide

Pattern format

Product information

SEWING LEVEL

SIZING

RECOMMENDED FABRIC

NOTIONS

Pattern features

BODICE

NECKLINE

SLEEVE

SKIRT

PDF pattern information

Model Details

Learn More

Related Posts

Fabric Requirements & Measurements

Body Measurements (in), sizes 0-16

Finished Garment Measurements (in), sizes 0-16

Body Measurements (cm), sizes 0-16

Finished Garment Measurements (cm), sizes 0-16

Fabric Requirements, sizes 0-16

Bodices

Sleeves

Skirts

See what our customers are making

Customer Reviews

Grafton Dress, Top & Skirt Mix & Match Pack

Grafton Dress, Top & Skirt Mix & Match Pack

Size Size guide

Pattern format

Product information

SEWING LEVEL

SIZING

RECOMMENDED FABRIC

NOTIONS

Pattern features

BODICE

NECKLINE

SLEEVE

SKIRT

PDF pattern information

Model Details

Learn More

Related Posts

Fabric Requirements & Measurements

Body Measurements (in), sizes 0-16

Finished Garment Measurements (in), sizes 0-16

Body Measurements (cm), sizes 0-16

Finished Garment Measurements (cm), sizes 0-16

Fabric Requirements, sizes 0-16

Bodices

Sleeves

Skirts

See what our customers are making

Customer Reviews

GET 10% OFF YOUR NEXT PURCHASE
